| MOQ: | 50 rolls |
| Price: | negotiable |
| Standard Packaging: | Waterproof paper or Shrink Wrapped , Carton |
| Delivery Period: | 15-25 days |
| Payment Method: | L/C, T/T |
| Supply Capacity: | 10000 square meter per day |
Hexagonal wire mesh is also named chicken wire,poultry wire, rabbit wire mesh.
Hexagonal wire netting is manufactured from steel wire which is then galvanized with a hot-dipped zinc coating that provides the metal with a corrosion-resistant surface.
If you opt for the PVC-coated version, your wire is galvanized and then coated with the PVC layer which offers added protection and weatherproofing.
We offer a range of different lengths, heights, holes sizes and wire thicknesses throughout our chicken wire range.
We also offer the majority of our roll sizes in the green PVC coated finish.
|
Specification List of Hexagonal Wire Mesh Fence
|
||
|
Opening
|
Wire Diameter(BWG)
|
|
|
In inch
|
In metric unit(mm)
|
|
|
1/4" x 1/4"
|
6.4mm x 6.4mm
|
22,23,24 |
|
3/8" x 3/8"
|
10.6mm x 10.6mm
|
19,20,21,22
|
|
1/2" x 1/2"
|
12.7mm x 12.7mm
|
16,17,18,19,20,21,22,23
|
|
5/8" x 5/8"
|
16mm x 16mm
|
18,19,20,21
|
|
3/4" x 3/4"
|
19.1mm x 19.1mm
|
16,17,18,19,20,21
|
|
1" x 1/2"
|
25.4mm x 12.7mm
|
16,17,18,19,20,21
|
|
1-1/2" x 1-1/2"
|
38mm x 38mm
|
14,15,16,17,18,19
|
|
1" x 2"
|
25.4mm x 50.8mm
|
14,15,16
|
|
2" x 2"
|
50.8mm x 50.8mm
|
12,13,14,15,16
|
| Mesh |
Wire (BWG) |
Standard roll size (m) |
| 3/8’’ | BWG27-24 | 0.50/0.60/0.80/1.00/1.20/1.50/1.80/2.00X10M/20M/30M/50M |
| 1/2’’ | BWG27-23 | 0.50/0.60/0.80/1.00/1.20/1.50/1.80/2.00X10M/20M/30M/50M |
| 5/8’’ | BWG26-22 | 0.50/0.60/0.80/1.00/1.20/1.50/1.80/2.00X10M/20M/30M/50M |
| 3/4’’ | BWG25-20 | 0.50/0.60/0.80/1.00/1.20/1.50/1.80/2.00X10M/20M/30M/50M |
| 1" | BWG27-19 | 0.50/0.60/0.80/1.00/1.20/1.50/1.80/2.00X10M/20M/30M/50M |
| 1 1/4" | BWG23-19 | 0.50/0.60/0.80/1.00/1.20/1.50/1.80/2.00X10M/20M/30M/50M |
| 1 1/2 " | BWG23-19 | 0.50/0.60/0.80/1.00/1.20/1.50/1.80/2.00X10M/20M/30M/50M |
| 2 " | BWG23-19 | 0.50/0.60/0.80/1.00/1.20/1.50/1.80/2.00X10M/20M/30M/50M |
| 2 1/2 " | BWG21-19 | 0.80/1.00/1.20/1.50/1.80/2.00X10M/20M/30M/50M |
| 3" | BWG20-18 | 1.00/1.20/1.50/1.80/2.00X20M/30M/50M |
| 4 " | BWG19-17 | 1.00/1.20/1.50/1.80/2.00X20M/30M/50M |
| We also can manufacture as customers’ specific requirements. | ||
a) Hexagonal wire nettings are also regarded as chicken mesh or bird cage netting
b) Mainly used in bird cages, tennis courts and light fencing for poultry farms
c) Used as light reinforcement for shatter-proof glass, cement, concrete, plastering and paving
Packing & Transportation pictures:
|
|
