| MOQ: | 50 rolls |
| Price: | negotiable |
| Standard Packaging: | 1) compression rolls, 5 rolls, 10 rolls, or more rolls as one bundle 2) 1 roll, 3 rolls or 5 rolls in one carton |
| Delivery Period: | 10 - 20 days |
| Payment Method: | L/C, T/T |
| Supply Capacity: | 2000 rolls per day |
1.The razor type (BTO-10, BTO-15,BTO-22,BTO-28,BTO-30,CBT-60/65)
2.The material of the main wire (low carbon steel wire, stainless steel wire)
3.The razor material (hot dip galvanized plate, stainless steel plate)
4.The wire diameter(2.5mm)
5.The razor thickness(0.4mm-0.6mm)
6.The coil diameter (450mm-960mm)
Razor barbed wire types:
1.Blade style
2.Single loop razor barbed wire
3.Cross type razor bared wire
4.Flat warp razor barbed wire
Electro galvanized core wire and blade
hot-dipped galvanized core wire and blade
stainless steel core wire and blade
PVC coated core wire and blade
Hot-dipped galvanized core wire+stainless steel blade
| Model | Thickness | Wire Diameter | Length | Width | Spacing |
| BTO-10 | 0.5±0.05 | 2.5±0.1 | 10±1 | 13±1 | 26±1 |
| BTO-12 | 0.5±0.05 | 2.5±0.1 | 12±1 | 15±1 | 26±1 |
| BTO-18 | 0.5±0.05 | 2.5±0.1 | 18±1 | 15±1 | 33±1 |
| BTO-22 | 0.5±0.05 | 2.5±0.1 | 22±1 | 15±1 | 34±1 |
| BTO-28 | 0.5±0.05 | 2.5±0.1 | 28±1 | 15±1 | 45±1 |
| BTO-30 | 0.5±0.05 | 2.5±0.1 | 30±1 | 18±1 | 45±1 |
| CBT-60 | 0.6±0.05 | 2.5±0.1 | 60±2 | 32±1 | 100±2 |
| CBT-65 | 0.6±0.05 | 2.5±0.1 | 65±2 | 21±1 | 100± |
Outside Diameter | No. of Loops | Standard Length per Coil | Type | Notes |
450 mm | 33 | 8M | CBT-65 | Single Coil |
500 mm | 41 | 10M | CBT-65 | Single Coil |
700 mm | 41 | 10M | CBT-65 | Single Coil |
960 mm | 53 | 13M | CBT-65 | Single Coil |
500 mm | 102 | 16M | BTO-10,15,22 | Cross type |
600 mm | 86 | 14M | BTO-10,15,22 | Cross type |
700 mm | 72 | 12M | BTO-10,15,22 | Cross type |
800 mm | 64 | 10M | BTO-10,15,22 | Cross type |
960 mm | 52 | 9M | BTO-10,15,22 | Cross type |
Protection, prevention, isolation. Widely used in industrial, mining enterprises, garden apartment, border posts, military field, prisons, detention center, government buildings and other national securit facilities.
|
|
