| MOQ: | 100pcs |
| Price: | negotiable |
| Standard Packaging: | in bundle, by pallet, wooden case or customized |
| Delivery Period: | 10-20days |
| Payment Method: | L/C, T/T |
| Supply Capacity: | 2000pcs per day |
Welded wire mesh is one popular materials in concrete, construction and industry. It is made of low carbon steel wire, PVC coated wire and stainless steel wire, after welding or before welding and surface zinc treating .The welded wire mesh are the most excellent anti-corrosion resistance among all the steel wire mesh products, it is also the most versatile wire mesh due to its wide application in different fields.
* Simple structure beautiful and practical.
* Stronge welded point
* Anti-erosion, Anti-aging, Anti-sunburn
* Extra long lifetime, lasting years longer than Galvanized Before Weld products
* Extreme strength, durability and resistance to rust, corrosion and harsh chemicals
If you need a welded mesh or fence in an area with prolonged exposure to corrosives, stainless steel products will meet the demands. Type 316 is recommended for salt water environments since it has a higher resistance to corrosion than Type 304.
1) Stainless steel welded wire mesh rolls
material: SS304,SS316,SS316L
wire diameter:1.5mm
aperture:15x15mm
roll size:1x30m
2)Stainless steel welded wire mesh panels
material: SS304,SS3016,SS316L
wire diameter:3mm,4mm,5mm,etc.
aperture:50x50mm,75x75mm,50x100mm,etc.
panel size:2x1m,2.2x1m,2x1.5m,etc.
|
Specification List of Welded Wire Mesh
|
||
|
Opening
|
Wire Diameter(BWG)
|
|
|
In inch
|
In metric unit(mm)
|
|
|
1/4" x 1/4"
|
6.4mm x 6.4mm
|
22,23,24
|
|
3/8" x 3/8"
|
10.6mm x 10.6mm
|
19,20,21,22
|
|
1/2" x 1/2"
|
12.7mm x 12.7mm
|
16,17,18,19,20,21,22,23
|
|
5/8" x 5/8"
|
16mm x 16mm
|
18,19,20,21
|
|
3/4" x 3/4"
|
19.1mm x 19.1mm
|
16,17,18,19,20,21
|
|
1" x 1/2"
|
25.4mm x 12.7mm
|
16,17,18,19,20,21
|
|
1-1/2" x 1-1/2"
|
38mm x 38mm
|
14,15,16,17,18,19
|
|
1" x 2"
|
25.4mm x 50.8mm
|
14,15,16
|
|
2" x 2"
|
50.8mm x 50.8mm
|
12,13,14,15,16
|
|
Technical Note:
1,Standard roll length: 30m;width: 0.5m to2m 2,Special sizes available at request 3,Packing: in waterproof paper in rolls. Custom packing available at request. |
||
Welded mesh panel is used in industry and agriculture building, transportation and mining for all such purposes like poultry houses, draining rack, fruit drying screen, fence.
|
|
